Ports & Marinas

Bringing life back to the
seawall.

Our vertical reef system is installed directly onto the underwater walls of ports and marinas, transforming passive concrete surfaces into active, measurable ecosystems.

The System

Active ecosystems, vertical by design.

Living Surface

Vertical reef system

Bio-receptive panels mount flush onto existing seawalls, pilings and quay structures in ports and marinas, converting concrete into colonisable habitat without disrupting marine operations.

Habitat Geometry

Microhabitat complexity

Crevices, overhangs and small caves are cast directly into the port´s infrastructure with our reef modular system, recreating the structural diversity that fish, molluscs and crustaceans need to settle.

Monitoring

Live biodiversity data

Periodic surveys feed a site-specific dashboard, so port operators can prove ecological uplift to regulators and stakeholders.

Deployment

Retrofit-ready system

Pre-fabricated, modular systems and bolt-on. Installation happens from the surface, no dewatering, no drydock, no disruption to berths or vessel traffic.

As seen in the news · 01 / 04

Denia.com

Refugios bajo el agua en Dénia: ecoingeniería en el Real Club Náutico para atraer la biodiversidad marina

Eco-engineering applied to harbour walls to create refuge for marine life.

Read article
Marine Lab team member reaching from a boat over a split above/below water view

Retrofit

Installed from the surface. Working from day one.

Each panel is pre-fabricated to match the wall geometry and lowered into place from the quayside. Professional diving teams then secure the system underwater with minimal disruption to port operations, allowing hundreds of square metres to be installed each week.

  • · Simple underwater anchoring system
  • · Operates during normal port activity
  • · Reversible & recyclable end-of-life

Process

From base survey to living walls.

01

Site assessment

Bathymetry, water quality and existing biodiversity baseline survey of the marina or port basin.

02

Panel design

Habitat geometry and panel layout are tuned to local species, tidal range and seawall geometry.

03

Retrofit install

Modules are installed by experienced diving teams, creating a stable, long-lasting habitat.

04

Monitor & report

Continuous telemetry plus periodic survey transects feed a transparent biodiversity dashboard.

At a glance

15×

Species uplift

Up to 100%

Wall coverage

< 30 min

Install per panel

0–8 m

Operational depth

Ready to regenerate your coastline?

Whether you're a port authority, a marine protected area, or a coastal developer, we'd love to hear about your project.

Start a Conversation

Or write to us at info@themarinelab.com
